Vibra-Tite VC-3 Threadmate
Vibra-Tite VC-3 Threadmate is one of the most versatile threadlockers available on the market. An alternative to traditional liquid lockers which cure to form a hard bond, VC-3 is a proprietary blend of thermoplastic elastomer resins designed to remain flexible and absorb vibration. The combination of inert/non-reactive amorphous resins creates a tough, semi solid layer inside the threads of a mated joint. VC-3 damps the vibrational energy transferred between the threads of a mated fastener, preventing fastener loosening and loss of clamp load. These unique differences make VC-3 coated fasteners truly adjustable, removable, and reusable.
- Description
- Product Specifications
Description
What makes VC-3 different?
- An acrylic polymer that damps and absorbs vibration
- Will not harden like anaerobic threadlockers
- Works with metal, wood, plastic (*see table) and more
- Fasteners are easily adjusted, removed and reused
- Works on fasteners of any shape or size, from tiny eyeglass screws to large construction bolts
- Works with internal or external threads
- Meets low out-gassing specifications (NASA SP-R-0022A, in accordance with ASTM E 595)
Excellent shelf life
Parts coated with Vibra-Tite VC-3 can be stored indefinitely before use.
Versatile
Adheres to both ferrous and non-ferrous metals, most platings, wood, and plastic (see table) screws.
Reliable, powerful lock
With exceptional reliability, VC-3 holds parts in place even during extreme vibration and shock.
Multiple reuses
Using steady pressure and standard hand tools, parts coated with VC-3 can be easily adjusted, removed, and reused.
Minimizes galling / stripping
Since Vibra-Tite VC-3 remains a thick, resilient, viscous resin, its cold flow properties actually minimize galling or stripping of soft threads during reuse.
Underwater installation
Unlike anaerobic threadlockers, VC-3 can be air dried and then installed into a mating part under both fresh and salt water.
Easy to use
Shake well before each use. Apply VC-3 a length of 1 to 1 ½ times the fastener diameter, filling threads 30-50%. Although material will be dry to touch within minutes, allow VC-3 to dry for at least 30 minutes (the longer the better), depending on part size. Fasteners are then ready for assembly or to be stored for later use.
Applications
- From tiny eyeglass screws to huge construction bolts, Vibra-Tite VC-3 is ideal for use on fasteners of any size.
- Mounting ski / snowboard bindings, plates and inserts.
- RC models (Drones, Airplanes, Helicopters).
- Bolts on motorcycles.
- In addition to supplying user-applied bottles and cans of Vibra-Tite VC-3 for on-the-job application, ND Industries can apply Vibra-Tite VC-3 at any of our regional service centers.
Material Properties
| Property | Data |
|---|---|
| Color | Red |
| Solvent | Methyl ethyl ketone |
| Cured form | Resilient plastic |
| Shelf life | Bottled: 5 Years from date of manufacture. Applied: Indefinite. |
| Chemical resistance | Offers resistance to most solvents (acts as a partial corrosion barrier) |
| Dries for use | 10-30 minutes+, depending on part size. |
| Drying method for bulk production | Best achieved using considerable airflow in addition to temperature not exceeding 130˚F |
| Operational temperature range | -65˚F to 165˚F (-54˚C to 74˚C) For other temperature applications, please contact us |
| Reusability | Using steady pressure and standard hand tools, parts coated with Vibra-Tite VC-3 can easily be adjusted, removed, and reused up to 5 times. |
| Minimizes Galling/Stripping | Since Vibra-Tite VC-3 remains a thick, resilient, viscous resin, its cold flow properties actually minimize galling or stripping of soft threads during reuse. |
| Engagement torque | Moderate |
| Breakaway torque | No distinct break; slow, fluid release as material cold flows |
| Standard coating length | 1 to 1 1/2 times diameter |
| Lead thread requirement | None |
| Thread Fill requirement | 30 – 50% of the thread root area |
| Also Known As | Vibra-Tite Formula 3 |
VC Formula Plastic Compatibility
Note that all VC products are applied and dried on a fastener first. So if your fastener is metal, it can likely be installed into any substrate as the solvent has already evaporated.
| Product | Solvent Base | Evaporation Rate | Plastic Compatibility |
|---|---|---|---|
| VC-3 | Methyl Ethyl Ketone | 3.8 | ECTFE, EPDM, FEP, Nylon 6/6, PE, PEEK, PET, PFA, PP, PPS, PTFE, TFE, UHMW |
| VC-4 | Ethyl Acetate | 4.2 | ECTFE, FEP, FLPE, HDPE*, LDPE*, Nylon 6/6, PEEK, PFA, PPS, PTFE, TFE, UHMW |
| VC-5 | Methyl Propyl Ketone | 2.4 | FEP, Nylon 6/6, PFA, PP, PPE, PTFE, TFE |
| VC-6 | Dimethyl Carbonate | 3.22 | ABS, FPM, Nylon 6/6, PC, PE, PEEK, PET, PP, PTFE, PVC, PVDF |
*Partial Compatibility
Meets or exceeds the following specifications
| Company Name | Specification / Part Number |
|---|---|
| Allied Signal | EMS73314, PCS5618 |
| Atlanta Research | SP 10234 |
| Delphi (Delco Electronics Systems) | Part No. 00047127 |
| Detroit Diesel | 9S244 |
| General Dynamics | 13233419 |
| Grumman Aerospace | GF105VP |
| Hazeltine Corporation | DWG. 260736 |
| Lockheed Martin | 11663357, 507-13-410, LMA-ML082B, P5407, P5407-1 |
| Meritor (Rockwell) | 005-2308-010 |
| Naval Sea Sys. Comm. | 5174855 |
| Northrup Grumman | 53352MK |
| US Army Missile Comm. | MIS-28867A |
| Leco Corporation | PRINT # 764-709 |
| Harris Corporation | DWG. P30-0013 |
| Lockheed Martin | CAGE # 18876 |
| US Army Missile Comm. | P5407-1 |
| National Stock # NSN | 8030-00-163-5792 |
Additional information
| Dry Time | |
|---|---|
| Country of Origin | |
| Cure Type | |
| Harmonized Tariff Schedule | |
| Available Sizes | 1 mL, 5 mL, 5 mL Blistercarded, 30 mL, 250 mL, 1 qt, 1 gal, 100pc Fishbowl |
| Color | |
| Base Material | |
| Shelf Life | Applied: Indefinite, Bottled: 5 years from date of manufacture. |
| Temp Range Low | |
| Temp Range High | |
| UN Identification | |
| National Stock Number | |
| k-Value |
